Square Cross Flow Cooling tower Installation Instructions

  1. According to the number in the list, string the left and right filling pieces into the filling frame cross arm separately, and then fix them with screws at both ends;
  2. Pay attention to the structure of the filling sheet, Its two ends are the air inlet section and the water collection section. The air inlet section contains a special resistance buffer structure that can be distinguished from the water collection section;
  3. The filling is installed layer by layer in order from top to bottom;
  4. After the filling is installed, the whole is inclined with the lower part facing the inside of the tower;
  5. Pay attention to the installation direction of the filling sheet, and ensure that the air inlet section of the filling sheet faces the outside of the tower.
